UHF connectors |
$419 | |
|
N connectors (Special Order) |
$499 |
| • | six (6) antenna ports - 1 to 60 MHz. |
| • | heavy aluminum case 4mm (158 mils) thick, IP 66 provides high level weather protection and RF proof capabilities |
| • | SO239 UHF or N teflon™ / gold pin connectors used |
| • | 10kV surge strength, 16 Amp sealed relays |
| • | stub compensated microstrip PCB architecture assures lowest SWR and insertion loss from 1.8 to 60 MHz |
| • | built-in surge protection |
| • | compatible with all 12V source driver band decoders |
| • | connects directly to Station Master™ |
| • | top cover screws protected against loss (very useful at tower) |
| • | easy wall or tower assembling thanks to special galvanized heavy double C-bolt, which allows using various diameter of the tower tube |
| • | unselected antenna ports are grounded |
| • | without power all antenna ports are grounded |
| • | each device is individually trimmed and tuned for best performance |
