| • | No serial or parallel port requires- just a USB port and sound card |
| • |
Complete "Computer <-> Radio" electrical isolation - bidirectional transformer isolation of sound card and rig - optical isolation between USB port and ALL digital signals: Radio Control (CAT), CW, PTT, FSK, and Amplifier PTT |
| • |
Compatible with most standard MS Windows based logging or control software - special microHAM "USB Device Router" program creates as many virtual COM ports as needed to support your favorite programs - customizable presets allow instantly changing microKEYER parameters to match the requirements of multiple applications |
| � |
Macintosh OS-X Support - compatible with and supports MacLoggerDX by Dog Park Software - compatible with and supported by cocoaModem and �H Router by W7AY |
| • |
Integrated computer control port for all radios CI-V, FIF-232, IF-232, RS-232 - fully supports Icom, Kenwood, Ten Tec, Yaesu and other radios |
| • |
Integrated K1EL WinKey™ chip with extended capabilities - front panel speed knob - nine (9) user programmable memories - PS/2 keyboard support for direct CW generation. - PS/2 keyboard/keypad support for instant CW message playback - PS/2 keyboard/keypad CW work without a computer connection - auto PTT - selectable side tone - all parameters are stored in EEPROM and reloaded on power up |
| • |
FSK keying output - capable of sending 5/6/7/8 bits and 1/1.5/2 stop bits - PS/2 keyboard support for direct FSK transmission without a computer - PS/2 keyboard support for instant FSK message playback - PS/2 keyboard works without a computer connection |
| • |
Unique Microphone/Sound Card/Radio audio switching - configurable audio priority microphone routing for SSB/Contest/SSTV - two audio outputs, one for radio front MIC IN, second for rear LINE IN - front panel audio level controls for setting computer and radio levels |
| • |
Independent keying buffer for Power Amplifier - extended range solid state output for low voltage T/R lines or QSK - relay isolated output for vintage PA with negative voltage T/R lines |
| • |
Footswitch input with programmable functions - programmable PTT activation delay in 1ms steps - selectable muting of CW and/or FSK when footswitch is closed |
| • |
Second independent PTT output for extended keying capabilities - PTT2 output for digital modes with "muted mic" |
| • |
Hot Switch protection with user defined timing - T/R sequencer for PTT keying outputs |
| • |
No external power adapter (where the radio
provides auxiliary power) - Computer part is powered from USB - Radio part is powered from transceiver or transceiver power supply |
| • |
Strong immunity from RFI - integrated chokes and filters for best RFI immunity - advanced shielding and circuit design to suppress RFI generation |
| • |
Input/Output connectors - Computer: USB, Sound Card: 3 x 3.5mm (1/8") - Radio: DB37, Microphone: RJ-45 and 3.5 mm (1/8") - Paddle - 1/4", PS/2 - MiniDIN6, Footswitch - RCA, Amplifier keying - RCA |
| • | Dual color LEDs for easy visual feedback of CW/FSK and PTT1/PTT2 |
| • | Metal/Aluminum case, powder coated and silk screened |
| • | Free firmware/software upgrades via internet |
